    4 Port GEPON OLT Switch FTTH Architecture Network 20KM Support 64 ONU GXPO GXSPON

    Ask Lasest Price
    Brand Name : KEXINT
    Model Number : EPON-OLT-EP7004
    Certification : ISO-9001 2015
    Price : $+398.11
    Payment Terms : T/T, D/A, L/C, D/P, Western Union, MoneyGram
    Supply Ability : 100+pcs+7day
    Delivery Time : 5
    • Product Details
    • Company Profile

    4 Port GEPON OLT Switch FTTH Architecture Network 20KM Support 64 ONU GXPO GXSPON

    4 Port GEPON OLT Switch FTTH Architecture Network 20KM Support 64 ONU


    EPON-OLT-EP7, the most effective access technology, is increasingly used in telecom broadband access, cable broadband access, FTTx, intelligent electric grid and surveillance.It is a small rack type EPON OLT. It consists of a EPON OLT and the network management card. I wors with EPON ONU series and ODN to establish a passive optic network.

    Each PON port of 4 ports EPON OLT supports 64 terminal ONUs. It supports 10~20km transmission distance at the base of high bandwidth, and supplies full line speed L2/L3 transition capacity.
    4 Port EPON OLT supports maximum 258 Logical Link Identifiers (LLID) and Dynamic Bandwidth Allocation (DBA). It is adapt to small fiber access network, such as towns, villages, which don’t have large quantity users. 4 Port EPON system greatly lowers the cost to establish network and assure high bandwidth. It is also adapt to FTTH/FTTB/FTTO projects, to implement fiber to the home, such as IP phone, Ethernet data and IPTV services access.

    Advantages:

    PON:

    1 1000BASE-PX20 SFP

    2 Support 64 ONUs

    3 Full duplex EPON port operating at 1.25G

    Standards compliance:

    1 IEEE 802.3ah

    2 CTC 2.x (China Telecom)

    3 IPMI version 2.0

    Security:

    Physical isolation between ONUs

    Triple churning with 128 bit AES encryption - downstream and upstream

    802.1x authenticator with remote administration

    High Qos:


    Each PON system supports maximum 128 Logical Link Identifier (LLID) and adopts AES-128 encryption to each LLID; support DBA function and SLA management function; support to debug different data flow through queue; support different stream weighting coefficient to fully guarantee QOS.

    8 priority queues with multiprotocol classifier including IEEE802.1q VLAN, IEEE802.1p priority, IPv6 priority, IPv4 COS

    DBA support flexible bandwidth allocation algorithms, such as fixed, assured, and best effort,with small granularity 128kbps.

    IGMP, and IP Multicast


    Powerful OAM Traits:


    4 port EPON OLT supports auto-discovery and auto-register, user line testing, terminal ONU fiber failure alert and power failure alert. It also contains abundant operation and manageable features such as MAC address limited and leached, IP address limited and leached, bandwidth control, VLAN, flow control.

    Perfect Management Function:


    Support CLI, Telnet, GUI and SNMP management function; Support telenet upgrade on line; support in-band/out-band management; support Telenet supervising and falut location.

    z CLI via telnet or console

    z Embedded Web Server to support Web-based management

    z Embedded SNMP agent to facilitate NMS management

    Specifications:

    ParameterSpecification
    Operating wavelength1310 (RX)/1490(TX)
    Optical power+2 ~ +7dBm
    Receiving sensitivity-27dBm
    Max distance20km
    Max splitter ratio1:64
    Capacity1 PON, 64 ONUs
    MAC4K
    Uplink port4 * GE port
    PON port4 * PON port
    Control portRJ45, RS232, to debug the device
    MTBF100,000 hours
    EPON traitsSupport IEEE802.3ah
    Support DBA with minimum1Kbps granularity adjustable
    Support 1Gbps up link and down link symmetrical bandwidth
    Support AES-128 encryption to each Logical Link Identifier
    Support powerful OAM function, implement telnet management, maintenance and upgrade
    Support auto discovery and auto register of ONU (real-time operation)



    Protocols supported

    Support IEEE802.3, IEEE802.3u, IEEE802.3ab
    Support IEEE802.1Q VLAN
    Support IEEE 802.1P QoS



    Network management

    Support GUI management based on SNMP
    Support Local serial interface management and local serial interface management and Telnet GUI management based on CLI





    Other functions

    Support 1GMPv1/v2 protocol report, query and leave message mouse
    Support DHCP Snooping
    Support Ipv4 address learning based at DHCP Snooping
    Support ARP Snooping, QoS etc


    Working Environment:


    ParameterSpecification
    Max optical power of the module cardDC-48V or AC220V
    Operating temperature-10~55℃
    Storage temperature-40~70℃
    Humidity5%~90% non-condensing
    Dimension320(length) ×440(width) ×44(height):mm


    Our advantages:
    1.Good reply: Your inquiry related to our products or price will be replied within 24 hours.
    2.OEM&ODM: We can help you to design or put your logo and company name into products.
    3.Remote Technical support&Full Technical Document
    4.Warranty: 1 year warranty( While the warranty is not responsible for those broken by violence or updated with other brands.)
    5.English software, English Indicator
    6.Professional, Very competitive price
    7.Large Stock, Fast Delivery
    8.Quality Assurance
